Lightweight Armoury Crate alternative for Asus laptops and ROG Ally. Control tool for ROG Zephyrus G14, G15, G16, M16, Flow X13, Flow X16, TUF, Strix, Scar and other models

^{中文版点这里}

Small and lightweight Armoury Crate alternative for Asus laptops offering almost same functionality without extra load and unnecessary services.

Works with all popular models, such as ROG Zephyrus G14, G15, G16, M16, Flow X13, Flow X16, Flow Z13, TUF Series, Strix or Scar Series, ProArt, Vivobook, Zenbook, ROG Ally / Ally X and many more!

⭐ If you like the app - please spread the word about it online

Support Project

• FAQ
• Setup and Requirements
• Troubleshooting
• Power User Settings

Josh Cravey	cbutters Tech

1. https://www.digitaltrends.com/computing/g-helper-armoury-crate-alternative/
2. https://binaryfork.com/ghelper-armoury-crate-alternative-10216/

1. Seamless and automatic GPU switching
2. All performance modes can be fully customized with power limits and fan curves
3. Lightweight. Doesn't install anything in your system. Just a single exe to run
4. Simple and clean native UI with easy access to all settings
5. FN-Lock and custom hotkeys

1. Performance modes: Silent - Balanced - Turbo (built-in, with default fan curves)
2. GPU modes: Eco - Standard - Ultimate - Optimized
3. Screen refresh rate control with display overdrive (OD)
4. Custom fan curve editor, power limits and turbo boost selection for every performance mode
5. Anime Matrix or Slash Lighting control including animated GIFs, clock and Audio visualizer
6. Backlight animation modes and colors
7. Hotkey handling
8. Monitor CPU and GPU temperature, fan speeds and battery status
9. Battery charge limit to preserve battery health
10. NVidia GPU overclocking and undervolting
11. XG Mobile Control
12. AMD CPU Undervolting
13. BIOS and Driver Updates
14. Asus Mice settings
15. Mini-led multi-zone switch
16. Flicker-free dimming and Visual Modes

• Performance Mode switching when on battery or plugged in
• Optimized GPU mode - disables dGPU on battery and enables when plugged in
• Auto Screen refresh rate (60Hz on battery and max Hz when plugged)
• Keyboard backlight timeout on battery or when plugged in

All Modes are baked in BIOS along with default fan curves and power limits and they are the same as in the Armoury Crate.

Each BIOS mode is paired with matching Windows Power Mode. You can adjust this setting under Fans + Power

1. Silent in BIOS + Best power efficiency power mode
2. Balanced (Performance in AC) in BIOS + Balanced power mode
3. Turbo in BIOS + Best performance power mode

1. Eco : only low power integrated GPU enabled, iGPU drives built in display
2. Standard (MS Hybrid) : iGPU and dGPU enabled, iGPU drives built in display
3. Ultimate: iGPU and dGPU enabled, but dGPU drives built in display (supported on 2022+ models)
4. Optimized: disables dGPU on battery (Eco) and enables when plugged in (Standard)

Currently supported models

• ROG Chakram X (P708)
• ROG Chakram Core (P511)
• ROG Gladius II and Gladius II Origin (P502 and P504)
• ROG Gladius II Wireless
• ROG Gladius III
• ROG Gladius III Wireless
• ROG Harpe Ace Aim Lab Edition
• ROG Keris Wireless
• ROG Keris II Ace
• ROG Strix Carry (P508)
• ROG Strix III Gladius III Aimpoint Wireless (P711)
• ROG Strix Impact III (P518)
• ROG Spatha X
• ROG Strix Impact II Wireless
• ROG Pugio
• ROG Pugio II
• TUF Gaming M4 Wireless (P306)
• TUF Gaming M3
• TUF Gaming M3 Gen II
• TUF Gaming M4 AIR
• TUF Gaming M5
• TX Gaming Mini

Huge thanks to @IceStormNG 👑 for contribution and research (!).

• Fn + F5 / Fn + Shift + F5 - Toggle Performance Modes forwards / backwards
• Ctrl + Shift + F5 / Ctrl + Shift + Alt + F5 - Toggle Performance Modes forwards / backwards
• Ctrl + Shift + F12 - Open G-Helper window
• Ctrl + M1 / M2 - Screen brightness Down / Up
• Shift + M1 / M2 - Backlight brightness Down / Up
• Fn + C - Fn-Lock
• Fn + Ctrl + F7 / F8 - Flicker-free dimming Down / Up
• Fn + Shift + F7 / F8 - Matrix / Slash Lighting brightness Down / Up
• Fn + Shift + F7 / F8 - Screenpad brightness Down / Up
• Ctrl + Shift + F20 - Mute Microphone
• Ctrl + Shift + Alt + F13 - Toggle Display Refresh Rate
• Ctrl + Shift + Alt + F14 - Eco GPU Mode
• Ctrl + Shift + Alt + F15 - Standard GPU Mode
• Ctrl + Shift + Alt + F16 - Silent
• Ctrl + Shift + Alt + F17 - Balanced
• Ctrl + Shift + Alt + F18 - Turbo
• Ctrl + Shift + Alt + F19 - Custom 1 (if exists)
• Ctrl + Shift + Alt + F20 - Custom 2 (if exists)
• Custom keybindings / hotkeys

• M + DPad Left / Right - Display Brightness
• M + DPad Up - Touch keyboard
• M + DPad Down - Show desktop
• M + Y - Toggle AMD overay
• M + X - Screenshot
• M + Right Stick Click - Controller Mode

---

G-Helper is NOT an operating system, firmware, or driver. It DOES NOT "run" your hardware in real-time anyhow.

It's an app that lets you select one of the predefined operating modes created by manufacturer (and stored in BIOS) and optionally(!) set some settings that already exist on your device same as Armoury Crate can. It does it by using the Asus System Control Interface "driver" that Armoury uses for it.

If you use equivalent mode/settings as in Armoury Crate - the performance or the behavior of your device won't be different.

The role of G-Helper for your laptop is similar to the role of a remote control for your TV.

• Linux Kernel for some basic endpoints in ASUS ACPI/WMI interface
• NvAPIWrapper for accessing Nvidia API
• Starlight for anime matrix communication protocol
• UXTU for undervolting using Ryzen System Management Unit
• AsusCtl for inspiration and some reverse engineering
